Centrifugal Pumps

The hydraulic motor features a fixed displacement internal gear design for smooth
operation. A double lip Teflon shaft seal provides excellent reliability even with
high hydraulic oil back pressure. The hardened stainless steel motor/pump shaft is
supported by two needle bearings and a ball bearing.

MODEL DESCRIPTION MAX MAX MAX HYD.
NUMBER GPM PSI GPM
9300 SERIES CI HYDRAULIC MOTOR-DRIVEN MODELS
9302C- Open/closed center systems, Viton/ceramic seals, 72 150 13 GPM
HM1C NPT ports 1-1/4" inlet, 1" outlet
9302C- Open/closed center systems, outlet. Viton/ceramic 65 96 6 GPM
HM2C seals, NPT ports 1-1/4" inlet, 1" outlet
9302C- Open/closed center systems, Viton/ceramic seals, 72 120 7 GPM
HM4C NPT ports 1-1/4" inlet, 1" outlet
9303C- Open/closed center systems, Viton/ceramic seals, 114 130 13 GPM
HM1C NPT ports 1-1/2" inlet, 1-1/4" outlet
9303C- Closed center systems, Viton/ceramic seal, NPT ports 97 95 6 GPM
HM2C
1-1/2" inlet, 1-1/4" outlet
PUMPS 9303C- Large open center systems, outlet. Viton/ceramic 125 98 24 GPM 9302C-HM2C
HM3C
seals, NPT ports 1-1/2" inlet, 1-1/4" outlet
93
7 GPM
115
9303C-
Open/closed center systems, Viton/ceramic seals,
HM4C
9303C- NPT ports 1-1/2" inlet, 1-1/4" outlet 147 145 16 GPM
Open/closed center systems, Viton/ceramic seals,
HM5C NPT ports 1-1/2" inlet, 1-1/4" outlet
9305C- Open/closed center systems, Viton/ceramic seals, 182 156 19 GPM
HM3C NPT ports 2" inlet, 1-1/2" outlet
9306C- Open/closed center systems, Viton/ceramic seals, 207 130 13 GPM
HM1C NPT ports 2" inlet, 1-1/2 outlet
9306C- Open/closed center systems, Viton/ceramic seals, 214 135 24 GPM
HM3C* NPT ports 2" inlet, 1-1/2 outlet
9306C- Open/closed center systems, Viton/ceramic seals, 212 140 17 GPM
HM5C* NPT ports 2" inlet, 1-1/2 outlet
9307C- Open/closed center systems, Viton/ceramic seals, Port 370 135 20 GPM
GM10 sizes: 3" NPT inlet, 2" NPT outlet
9307C- Open/closed center systems, Viton/ceramic seals, Port 370 135 23 GPM 9307C-GM10
GM12 sizes: 3" NPT inlet, 2" NPT outlet

Life Guard® silicon carbide seal - Add suffix “B” (i.e.: 9305C-HM3C-B)

NEW ForceField™ seal technology
• Eliminates dry run
• Eliminates chemical and fertilizer bonding failures
• Self-regulating chamber designed to provide pressure when needed and safe
serviceability when it is not needed
• Direct drop-in for current 9307 designs

MODEL DESCRIPTION MAX MAX MAX HYD.
NUMBER GPM PSI GPM
9300 SERIES CI HYDRAULIC MOTOR-DRIVEN MODELS WITH
FORCEFIELD™ TECHNOLOGY

9307CWS- Open/closed center systems, 300 universal flange inlet 370 135 23 GPM
GM12 x 220 universal flange outlet 9307CWS-GM12
