TeeJet Nozzle Parts
Teejet Spray Nozzle TeeJet Nozzle Caps
Secure interchangeable TeeJet tips to the various nozzle
bodies.18032A-NYB winged TeeJet cap allows quick change
of spray tips with no tool required.
Type T or TT 5053 Optional Spray CP1325
Nozzle Body Strainer Tip Gasket Tip TeeJet Cap
CP5871-BU CP1325 CP18032A-NYB
11750 TeeJet Check Valve CAP NUMBER DESCRIPTION
For larger capacity TeeJet nozzles where CP1325 Brass
strainers are not required. Ball check opens at CP8027-NYB Nylon
5 PSI (0.34 bar), 10 PSI (0.7 bar) spring also CP8027-1-NYB Nylon (Extra-long size)
available. Recommended for flow rates from CP1325-AL Aluminum
.40 to 1.5 GPM (1.5–5.7 l/min). Made in
choice of stainless steel, brass, aluminum or CP1325-SS Stainless Steel
polypropylene with stainless steel ball and CP18032A-NYB Winged Cap, Nylon
spring. CP3819 Brass, use with 3/4T and 3/4TT body
CP3819-SS Stainless Steel, use with 3/4T and 3/4TT body
TeeJet Nozzle Bodies CP20230 Brass, use with ceramic disc-cores
45° Nozzle Body
CP1322
Ideal for use with FullJet®,
FloodJet® and Turbo BOOM COMPONENTS
BODY NOZZLE MALE MATERIAL FloodJet® nozzles. Can be used
NUMBER TYPE SIZE with QJ4676 Quick TeeJet® cap
CP1336 1/8TT 1/8" Brass or standard 4676 outlet adapter.
Made of polypropylene.
CP1322 1/4TT 1/4" Brass
CP8028-NYB 1/4TT-NYB 1/4" Nylon
BODY NUMBER INLET OUTLET
CP1322-I 1/4TT-I 1/4" Steel 22669-1/4-PPB 1/4"(M) 11/16"–16 (M)
CP1322-SS 1/4TT-SS 1/4" Stainless Steel
CP1324 3/8TT 3/8" Brass
CP1340 1/2TT 1/2" Brass Clamp Assemblies
Consist of upper and
CP3818 3/4TT 3/4" Brass lower clamps and bolt
CP3818-SS 3/4TT 3/4" Stainless Steel for use with hose shank
nozzle bodies.
AA111-1
CP1321 PART TO CLAMP ON
AA111-1/2 1/2" Pipe (1-3/16" & 7/8" O.D. Tubings)
BODY NOZZLE MALE MATERIAL AA111-3/4 3/4" Pipe (1" & 1-1/16" O.D. Tubings)
NUMBER TYPE SIZE AA111-1 1" Pipe (1-1/8", 1-1/4" & 1-3/8" O.D. Tubings)
CP1335 1/8T 1/8" Brass AA111-1-1/4 1-1/4" Pipe (1-/16" & 1-11/16" O.D. Tubings)
CP1321 1/4T 1/4" Brass
CP12094-NYB 1/4T-NYB 1/4" Nylon
CP1321-I 1/4T-I 1/4" Steel
CP1321-SS 1/4T-SS 1/4" Stainless Steel AA111SQ-1
CP1323 3/8T 3/8" Brass PART TO CLAMP ON
CP1339 1/2T 1/2" Brass AA111SQ-1 1" Square Tubing
CP3817 3/4T 3/4" Brass AA111SQ-1-1/4 1-1/4" Square Tubing
CP3817-SS 3/4T 3/4" Stainless Steel
AA111SQ-1-1/2 1-1/2" Square Tubing
