TeeJet Hose Shank Nozzle Bodies

Hose Shank Nozzle Split Eyelet Nozzle Bodies
Bodies
For Wet Booms
• Mounting on 1/2", 3/4" or 1" pipe or tubing.
• 25775-NYB mounts to 3/8" (9.5 mm) hole
drilled in pipe or tubing.
• 7421 mounts to 9/32" (7.2 mm) hole
Single Hose drilled in pipe or tubing.
Connection 8121-NYB-406TD • 25775-NYB and 7421 feature
PART NUMBER TO FIT MATERIAL 11/16"-16 TeeJet threaded outlets.
Hose ID • 25888-NYB features 1/4" (M) NPT
threaded outlet.
6471B-400TD 1/4" Brass
8121-NYB-406TD 3/8" Nylon
25775-NYB
8121-NYB-540TD 1/2" Nylon Operating pressures up
9191B-531TD 1/2" Brass to 150 PSI (10 bar) 25775-3/4T-NYB

BOOM COMPONENTS
PART NUMBER MATERIAL TO CLAMP ON
1/2" Pipe
25775-1/2T-NYB Nylon 13/16" O.D. Tubing
25888-1/2-NYB
7/8" O.D. Tubing
3/4" Pipe
25775-3/4T-NYB Nylon 1" O.D. Tubing
25888-3/4-NYB
11/16" O.D. Tubing
Double Hose 25775-1T-NYB 1" Pipe
Connection 8120-NYB-406TD 25888-1-NYB Nylon 1-1/4" O.D. Tubing
1-3/8" O.D. Tubing
PART NUMBER TO FIT MATERIAL
Hose ID
6472B-400TD 1/4" Brass
8120-NYB-406TD 3/8" Nylon How to Order:
Specify split eyelet assembly number.
8120-NYB-540TD 1/2" Nylon Examples: 7421-1/2T-SS
9192B-531TD 1/2" Brass 25775-1/2T-NYB
7421
Operating pressures up
to 250 PSI (17 bar)
7421-3/4T
PART NUMBER MATERIAL TO CLAMP ON
7421-1/2T Brass 1/2"Pipe
7421-1/2T-SS Stainless Steel 13/16" O.D. Tubing
7421-1/2T-NYB Nylon 7/8" O.D. Tubing
Triple Hose 8124-NYB-406TD 7421-3/4T Brass 3/4" Pipe
Connection 7421-3/4T-SS Stainless Steel 1" O.D. Tubing
PART NUMBER TO FIT MATERIAL 7421-3/4T-NYB Nylon 1-1/16" O.D. Tubing
Hose ID 7421-1T Brass
1" Pipe
8124-NYB-406TD 3/8" Nylon 7421-1T-SS Stainless Steel 1-1/4" O.D. Tubing
8124-NYB-540TD 1/2" Nylon 7421-1T-NYB Nylon 1-3/8" O.D. Tubing
