XR TeeJet - Extended Range Flat Spray Tips

DROP CAPACITY CAP 20"
PSI SIZE ONE ONE
NOZZLE NOZZLE GPA GALLONS PER 1000 SQ. FT.
IN GPM IN 4 5 6 8 10 12 15 20 2 3 4 5
80 | 100 OZ/ MIN MPH MPH MPH MPH MPH MPH MPH MPH MPH MPH MPH MPH
15 M F 0.061 7.8 4.5 3.6 3.0 2.3 1.8 1.5 1.2 0.91 .021 .014 0.10 0.08 Features:
20 F F 0.071 9.1 5.3 4.2 3.5 2.6 2.1 1.8 1.4 1.1 0.24 0.16 0.12 0.10 • Excellent spray distribution over a wide
30 F F 0.087 11 6.5 5.2 4.3 3.2 2.6 2.2 1.7 1.3 0.30 0.20 0.15 0.12 range of pressures—15–60 PSI (1–4 bar).
40 F F F VF 0.10 13 7.4 5.9 5.0 3.7 3.0 2.5 2.0 1.5 0.34 0.32 0.17 0.14 • Ideal for rigs equipped with sprayer
controllers.
2.7
(100 MESH) XR11001 60 M F VF 0.092 15 8.9 7.1 5.9 4.5 3.6 3.0 2.4 1.8 0.41 0.27 0.20 0.16 • Reduces drift at lower pressures, better
1.6
6.5
50
5.4
2.2
14
0.37 0.25 0.19 0.15
3.3
4.1
8.2
0.11
XR8001
0.12
F
4.6
coverage at higher pressures.
15
0.31 0.21 0.16 0.13
1.8
1.4
6.8
3.4
5.5
12
2.7
2.3
20
7.7
3.2
2.6
1.9
4.8
17
9.7
F
30 M F F 0.11 14 8.2 6.5 5.4 4.1 3.3 2.7 2.2 1.6 0.37 0.25 0.19 0.15 • Available in stainless steel, ceramic and
0.13
6.4
0.44 0.29 0.22 0.18
3.9
polymer in 80° and 110° spray angles with
40 F F 0.15 19 11.1 8.9 7.4 5.6 4.5 3.7 3.0 2.2 0.51 0.34 0.26 0.20 VisiFlo® color-coding.
XR80015 50 F F 0.17 22 12.6 10.1 8.4 6.3 5.0 4.2 3.4 2.5 0.58 0.39 0.29 0.23
XR110015 60 F F 0.18 23 13.4 10.7 8.9 6.7 5.3 4.5 3.6 2.7 0.61 0.41 0.31 0.24 • Ceramic is available with corrosive resistant
15 M M 0.12 15 8.9 7.1 5.9 4.5 3.6 3.0 2.4 1.8 0.41 0.27 0.20 0.16 polypropylene VisiFlo color-coded tip holder
20 M F 0.14 18 10.4 8.3 6.9 5.2 4.2 3.5 2.8 2.1 0.48 0.32 0.24 0.19 in 80° capacities 03–08 and 110° capacities
30 M F 0.17 22 12.6 10.1 8.4 6.3 5.0 4.2 3.4 2.5 0.58 0.39 0.29 0.23 02–08.
40 F F 0.20 26 14.9 11.9 9.9 7.4 5.9 5.0 4.0 3.0 0.68 0.45 0.34 0.27 • XR110025 only available in VK.
XR8002 50 F F 0.22 28 16.3 13.1 10.9 8.2 6.5 5.4 4.4 3.3 0.75 0.50 0.37 0.30 • Brass available in 110° only.
XR11002 60 F F 0.24 31 17.8 14.3 11.9 8.9 7.1 5.9 4.8 3.6 0.82 0.54 0.41 0.33 • Automatic spray alignment with
15 M 0.15 19 11.1 8.9 7.4 5.6 4.5 3.7 3.0 2.2 0.51 0.34 0.26 0.20 25612-*-NYR Quick TeeJet® cap and gasket.
20 M 0.18 23 13.4 10.7 8.9 6.7 5.3 4.5 3.6 2.7 0.61 0.41 0.31 0.24 • Automatic spray alignment for sizes 10 and
30 F 0.22 28 16.3 13.1 10.9 8.2 6.5 5.4 4.4 3.3 0.75 0.50 0.37 0.30 15 with 25610-*-NYR Quick TeeJet cap and
40 F 0.25 32 18.6 14.9 12.4 9.3 7.4 6.2 5.0 3.7 0.85 0.57 0.43 0.34
XR80025 50 F 0.28 36 21 16.6 13.9 10.4 8.3 6.9 5.5 4.2 0.95 0.63 0.48 0.38 gasket.
XR110025 60 F 0.31 40 23 18.4 15.3 11.5 9.2 7.7 6.1 4.6 1.1 0.70 0.53 0.42
15 M M 0.18 23 13.4 10.7 8.9 6.7 5.3 4.5 3.6 2.7 0.61 0.41 0.31 0.24
20 M M 0.21 27 15.6 12.5 10.4 7.8 6.2 5.2 4.2 3.1 0.71 0.48 0.36 0.29 PUMPS
30 M F 0.26 33 19.3 15.4 12.9 9.7 7.7 6.4 5.1 3.9 0.88 0.59 0.44 0.35
40 M F 0.30 38 22 17.8 14.9 11.1 8.9 7.4 5.9 4.5 1.0 0.68 0.51 0.41
XR8003 50 M F 0.34 44 25 20 16.8 12.6 10.1 8.4 6.7 5.0 1.2 0.77 0.58 0.46
XR11003 60 F F 0.37 47 27 22 18.3 13.7 11.0 9.2 7.3 5.5 1.3 0.84 0.63 0.50
15 M 0.21 27 15.6 12.5 10.4 7.8 6.2 5.2 4.2 3.1 0.71 0.48 0.36 0.29 SPRAY TIPS & NOZZLES
20 M 0.25 32 18.6 14.9 12.4 9.3 7.4 6.2 5.0 3.7 0.85 0.57 0.43 0.34
(50 MESH) 30 M 0.30 38 22 17.8 14.9 11.1 8.9 7.4 5.9 4.5 1.0 0.68 0.51 0.41
26
0.35
45
17.3 13.0 10.4
21
8.7
0.79 0.60 0.48
40
6.9
5.2
M
1.2
50
XR80035
32
60 F F 0.39 50 29 23 19.3 14.5 11.6 9.7 7.7 5.8 1.3 0.88 0.66 0.53
0.97 0.73 0.58
26
1.5
21
6.4
0.43
16.0 12.8 10.6 8.5
55
15 C M 0.24 31 17.8 14.3 11.9 8.9 7.1 5.9 4.8 3.6 0.82 0.54 0.41 0.33
20 C M 0.28 36 21 16.6 13.9 10.4 8.3 6.9 5.5 4.2 0.95 0.63 0.48 0.38
30 M M 0.35 45 26 21 17.3 13.0 10.4 8.7 6.9 5.2 1.2 0.79 0.60 0.48
40 M M 0.40 51 30 24 19.8 14.9 11.9 9.9 7.9 5.9 1.4 0.91 0.68 0.54
XR8004 50 M F 0.45 58 33 27 22 16.7 13.4 11.1 8.9 6.7 1.5 1.0 0.77 0.61
XR11004 60 M F 0.49 63 36 29 24 18.2 14.6 12.1 9.7 7.3 1.7 1.1 0.83 0.67
15 C M 0.31 40 23 18.4 15.3 11.5 9.2 7.7 6.1 4.6 1.1 0.70 0.53 0.42
20 C M 0.35 45 26 21 17.3 13.0 10.4 8.7 6.9 5.2 1.2 0.79 0.60 0.48
30 C M 0.43 55 32 26 21 16.0 12.8 10.6 8.5 6.4 1.5 0.97 0.73 0.58
40 M M 0.50 64 37 30 25 18.6 14.9 12.4 9.9 7.4 1.7 1.1 0.85 0.68
XR8005 50 M M 0.56 72 42 33 28 21 16.6 13.9 11.1 8.3 1.9 1.3 0.95 0.76
XR11005 60 M F 0.61 78 45 36 30 23 18.1 15.1 12.1 9.1 2.1 1.4 1.0 0.83 XR11004-VS
15 C C 0.37 47 27 22 18.3 13.7 11.0 9.2 7.3 5.5 1.3 0.84 0.63 0.50
20 C C 0.42 54 31 25 21 15.6 12.5 10.4 8.3 6.2 1.4 1.0 0.71 0.57
30 C M 0.52 67 39 31 26 19.3 15.4 12.9 10.3 7.7 1.8 1.2 0.88 0.71 Spacing
40 C M 0.60 77 45 36 30 22 17.8 14.9 11.9 8.9 2.0 1.4 1.0 0.82
XR8006 50 C M 0.67 86 50 40 33 25 19.9 16.6 13.3 9.9 2.3 1.5 1.1 0.91 Spray
XR11006 60 C M 0.73 93 54 43 36 27 22 18.1 14.5 10.8 2.5 1.7 1.2 0.99 Height
15 VC C 0.49 63 36 29 24 18.2 14.6 12.1 9.7 7.3 1.7 1.1 0.83 0.67
20 VC C 0.57 73 42 34 28 21 16.9 14.1 11.3 8.5 1.9 1.3 0.97 0.78
30 C C 0.69 88 51 41 34 26 20 17.1 13.7 10.2 2.3 1.6 1.2 0.94
40 C C 0.80 102 59 48 40 30 24 19.8 15.8 11.9 2.7 1.8 1.4 1.1 Optimum Spray Height
XR8008 50 C M 0.89 114 66 53 44 33 26 22 17.6 13.2 3.0 2.0 1.5 1.2
XR11008 60 C M 0.98 125 73 58 49 36 29 24 19.4 14.6 3.3 2.2 1.7 1.3 20
15 VC 0.61 78 45 36 30 23 18.1 15.1 12.1 9.1 2.1 1.4 1.0 0.83
20 VC 0.71 91 53 42 35 26 21 17.6 14.1 10.5 2.4 1.6 1.2 0.97 80º 30"
30 C 0.87 111 65 52 43 32 26 22 17.2 12.9 3.0 2.0 1.5 1.2
40 C 1.00 128 74 59 50 37 30 25 19.8 14.9 3.4 2.3 1.7 1.4 110º 20"
XR80010 Ɨ 50 C 1.12 143 83 67 55 42 33 28 22 16.6 3.8 2.5 1.9 1.5
XR110010 Ɨ 60 M 1.22 156 91 72 60 45 36 30 24 18.1 4.1 2.8 2.1 1.7
15 XC 0.92 118 68 55 46 34 27 23 18.2 13.7 3.1 2.1 1.6 1.3 ɫ Available in all stainless steel only.
20 XC 1.06 136 79 63 52 39 31 26 21 15.7 3.6 2.4 1.8 1.4
30 VC 1.30 166 97 77 64 48 39 32 26 19.3 4.4 2.9 2.2 1.8 How to Order: Specify tip number.
40 C 1.50 192 111 89 74 56 45 37 30 22 5.1 3.4 2.6 2.0 Example: TTI11004-VP – Polymer
XR80015 Ɨ 50 C 1.68 215 125 100 83 62 50 42 33 25 5.7 3.8 2.9 2.3 w/VisiFlo® color-coding
XR110015 Ɨ 60 C 1.84 236 137 109 91 68 55 46 36 27 6.3 4.2 3.1 2.5
