Page 73 - 2022 Online Catalog
P. 73
www.bigwsales.com
Polypropylene Bolted Ball Valves
PART NO DESCRIPTION
Features:
4 BOLT VALVES • FKM (viton type) seals.
• Precision molded polypropylene is reinforced with
V050 1/2" Full Port Valve fiberglass for additional strength.
V075 3/4" Full Port Valve • Self-aligning ball moves freely against the PTFE seats
V100 1" Standard Port Valve for smooth operation. The valve opens and closes
V100FP 1" Full Port Valve with very little pressure on the handle.
• Ball is diamond turned, after molding, to make it
V125 1-1/4" Standard Port Valve spherically perfect, which provides precise contact
V125FP 1-1/4" Full Port Valve between ball and seats.
V150 1-1/2" Full Port Valve • PTFE self-lubricating stem bushings and seats
V200 2" Standard Port Valve cannot stick or bind.
• Stainless steel bolts.
Mounting Brackets
V10271 V10270
Features for Locking Device: VALVES
• 304 Stainless steel construction.
• Installs under valve handle.
• Comes complete with handle
and locking device.
V25270 V25271 • Padlock not included*
PART NO DESCRIPTION VALVE USED
MOUNTING BRACKETS
V10270 Straight Mounting Bracket V100FP & V125
V10271 90° Mounting Bracket V100FP & V125
V25270 Straight Mounting Bracket V150 & V200 PART NO DESCRIPTION VALVE USED
V25271 90° Mounting Bracket V150 & V200
LOCKING DEVICE
VL20153 Locking Device V125FP, V150 & V200
Features for Handle Risers:
• Allows extra clearance between handle and body PART NO DESCRIPTION
for tight spaces.
HANDLE RISERS
V10153138BL 1" x 1-3/8" Handle Offset
V10153138 1" x 1-3/8" Handle Offset
V20153138BL 2" x 1-3/8" Handle Offset
V20153138 2" x 1-3/8" Handle Offset
V25153138BL 2" FP x 1-3/8" Handle Offset
V25153138 2" FP x 1-3⁄8" Handle Offset
