Page 259 - 2022 Online Catalog

www
www.bigwsales.com.bigwsales.com
FloodJet - Wide Angle Flat Spray Tips

How to order:
Specify tip number.
Examples:
TK-VS5 – Stainless Steel with VisiFlo® color-coding
TK-VP3 – Polymer with VisiFlo color-coding
1/4K-5 – Brass
TK-SS5 – Stainless Steel
1/8K-SS5 – Stainless Steel
1/4K
QCK-SS100 – Stainless Steel with VisiFlo® color-coding FloodJet QCK TK-VP TK-VS
(1⁄8" – 1" NPT) Quick FloodJet® FloodJet® FloodJet

GPA 60" GPA 60"
PART PSI CAP 1 PART PSI CAP 1
NUMBER NOZZLE 4 5 6 8 10 12 15 20 NUMBER NOZZLE 4 5 6 8 10 12 15 20
IN GPM MPH MPH MPH MPH MPH MPH MPH MPH IN GPM MPH MPH MPH MPH MPH MPH MPH MPH
10 3.00 74 59 50 37 30 25 19.8 14.9 10 10.0 248 198 165 124 99 83 66 50
3/8K-30
TK-30 3/4K-100
20 4.24 105 84 70 52 42 35 28 21 20 14.1 349 279 233 174 140 116 93 70
30 5.20 129 103 86 64 51 43 34 26 30 17.3 428 343 285 214 171 143 114 86
QCK-30 QCK-100
40 6.00 149 119 99 74 59 50 40 30 40 20.0 495 396 330 248 198 165 132 99
10 3.50 87 69 58 43 35 29 23 17.3 10 11.0 272 218 182 136 109 91 73 54
20 4.95 123 98 82 61 49 41 33 25 20 15.6 386 309 257 193 154 129 103 77
3/8K-35 3/4K-110
30 6.06 150 120 100 75 60 50 40 30 30 19.1 473 378 315 236 189 158 126 95
40 7.00 173 139 116 87 69 58 46 35 40 22.0 545 436 363 272 218 182 145 109 PUMPS
[3/8K, 10 4.00 99 79 66 50 40 33 26 19.8 [1/2K, 10 12.0 297 238 198 149 119 99 79 59
1/2K]-40 3/4K]-120
20 5.66 140 112 93 70 56 47 37 28 20 17.0 421 337 281 210 168 140 112 84
30 6.93 172 137 114 86 69 57 46 34 30 20.8 515 412 343 257 206 172 137 103
QCK-40 QCK-120 SPRAY TIPS & NOZZLES
40 8.00 198 158 132 99 79 66 53 40 40 24.0 594 475 396 297 238 198 158 119
10 4.50 111 89 74 56 45 37 30 22 10 14.0 347 277 231 173 139 116 92 69
20 6.36 157 126 105 79 63 52 42 31 20 19.8 490 392 327 245 196 163 131 98
3/8K-45 3/4K-140
30 7.79 193 154 129 96 77 64 51 39 30 24.2 599 479 399 299 240 200 160 120
40 9.00 223 178 149 111 89 74 59 45 40 28.0 693 554 462 347 277 231 185 139
10 5.00 124 99 83 62 50 41 33 25 10 15.0 371 297 248 186 149 124 99 74
1/2K-50
20 7.07 175 140 117 87 70 58 47 35 20 21.1 525 420 350 262 210 175 140 105
QCK-150
30 8.66 214 171 143 107 86 71 57 43 30 26.0 644 515 429 322 257 215 172 129
QCK-50
40 10.0 248 198 165 124 99 83 66 50 40 30.0 743 594 495 371 297 248 198 149
10 6.00 149 119 99 74 59 50 40 30 10 16.0 396 317 264 198 158 132 106 79
1/2K-60
20 8.49 210 168 140 105 84 70 56 42 20 22.6 559 447 373 280 224 186 149 112
3/4K-160
30 10.4 257 206 171 129 103 86 69 51 30 27.7 686 548 457 343 274 229 183 137
QCK-60
40 12.0 297 238 198 149 119 99 79 59 40 32.0 792 634 528 396 317 264 211 158
10 7.00 173 139 116 87 69 58 46 35 10 18.0 446 356 297 223 178 149 119 89
3/4K-180
20 9.90 245 196 163 123 98 82 65 49 20 25.5 631 505 421 316 252 210 168 126
1/2K-70
30 12.1 300 240 200 150 120 100 80 60 30 31.2 772 618 515 386 309 257 206 157
QCK-180
40 14.0 347 277 231 173 139 116 92 69 40 36.0 891 713 594 446 356 297 238 178
10 8.00 198 158 132 99 79 66 53 40 10 21.0 520 416 347 260 208 173 139 104
[1/2K,
3/4K]-80 20 11.3 280 224 186 140 112 93 75 56 3/4K-210 20 29.7 735 588 490 368 294 245 196 147
30 13.9 344 275 229 172 138 115 92 69 30 36.4 901 721 601 450 360 300 240 180
QCK-80 QCK-210
40 16.0 396 317 264 198 158 132 106 79 40 42.0 1040 832 693 520 416 347 277 208
10 9.00 223 178 149 111 89 74 59 45 Note: Always double check your application rates.
[1/2K, 20 12.7 314 251 210 157 126 105 84 63
3/4K]-90 Tabulations are based on spraying water at 70°F (21°C).
30 15.6 386 309 257 193 154 129 103 77
40 18.0 446 356 297 223 178 149 119 89
