Turbo FloodJet - Wide Angle Flat Spray Tips

Features:
• Excellent spray distribution for uniform coverage along the boom.
• Nozzle design incorporates a pre-orifice to produce larger droplets for less drift.
• Large, round orifice reduces clogging.
• Stainless steel or polymer with VisiFlo® color-coding band for easy size identification.
• Can be used with CP25600-*-NYR Quick TeeJet® cap and gasket for automatic alignment.

CAPACITY CAPACITY 40" 20"
PART PSI DROP ONE ONE PUMPS
NUMBER SIZE NOZZLE NOZZLE GPA GALLONS PER 1000
IN GPM IN SQ. FT.
OZ/ MIN 4 5 6 8 10 12 15 20 2 3 4 5
MPH MPH MPH MPH MPH MPH MPH MPH MPH MPH MPH MPH
10 UC 0.20 26 7.4 5.9 5.0 3.7 3.0 2.5 2.0 1.5 0.68 0.45 0.34 0.27 SPRAY TIPS & NOZZLES
20 XC 0.28 36 10.4 8.3 6.9 5.2 4.2 3.5 2.8 2.1 0.95 0.63 0.48 0.38
TF-ɫ2
30 XC 0.35 45 13.0 10.4 8.7 6.5 5.2 4.3 3.5 2.6 1.2 0.79 0.60 0.48
40 VC 0.40 51 14.9 11.9 9.9 7.4 5.9 5.0 4.0 3.0 1.4 0.91 0.68 0.54
10 UC 0.25 32 9.3 7.4 6.2 4.6 3.7 3.1 2.5 1.9 0.85 0.57 0.43 0.34
TF-ɫ2.5 20 UC 0.35 45 13.0 10.4 8.7 6.5 5.2 4.3 3.5 2.6 1.2 0.79 0.60 0.48 TF-VS2
30 XC 0.43 55 16.0 12.8 10.6 8.0 6.4 5.3 4.3 3.2 1.5 0.97 0.73 0.58
(50 MESH) 40 XC 0.50 64 18.6 14.9 12.4 9.3 7.4 6.2 5.0 3.7 1.7 1.1 0.85 0.68 Spacing
11.1
8.9
3.7
38
UC
4.5
0.30
7.4
3.0
2.2
1.0 0.68 0.51 0.41
10
5.6
TF-ɫ3 20 UC 0.42 54 15.6 12.5 10.4 7.8 6.2 5.2 4.2 3.1 1.4 0.95 0.71 0.57 Spray
30 XC 0.52 67 19.3 15.4 12.9 9.7 7.7 6.4 5.1 3.9 1.8 1.2 0.88 0.71 Height
40 XC 0.60 77 22 17.8 14.9 11.1 8.9 7.4 5.9 4.5 2.0 1.4 1.0 0.82
10 UC 0.40 51 14.9 11.9 9.9 7.4 5.9 5.0 4.0 3.0 1.4 0.91 0.68 0.54
TF-ɫ4 20 UC 0.57 73 21 16.9 14.1 10.6 8.5 7.1 5.6 4.2 1.9 1.3 0.97 0.78 Optimum Spray Height
30 XC 0.69 88 26 20 17.1 12.8 10.2 8.5 6.8 5.1 2.3 1.6 1.2 0.94 20
40 XC 0.80 102 30 24 19.8 14.9 11.9 9.9 7.9 5.9 2.7 1.8 1.4 1.1
10 UC 0.50 64 18.6 14.9 12.4 9.3 7.4 6.2 5.0 3.7 1.7 1.1 0.85 0.68 20º 24"
TF-ɫ5 20 UC 0.71 91 26 21 17.6 13.2 10.5 8.8 7.0 5.3 2.4 1.6 1.2 0.97 30º 30"
30 UC 0.87 111 32 26 22 16.1 12.9 10.8 8.6 6.5 3.0 2.0 1.5 1.2 40º 39"
40 XC 1.00 128 37 30 25 18.6 14.9 12.4 9.9 7.4 3.4 2.3 1.7 1.4
10 UC 0.75 96 28 22 18.6 13.9 11.1 9.3 7.4 5.6 2.6 1.7 1.3 1.0
TF-ɫ7.5 20 UC 1.06 136 39 31 26 19.7 15.7 13.1 10.5 7.9 3.6 2.4 1.8 1.4 How to Order:
30 UC 1.30 166 48 39 32 24 19.3 16.1 12.9 9.7 4.4 2.9 2.2 1.8 Specify tip number.
40 XC 1.50 192 56 45 37 28 22 18.6 14.9 11.1 5.1 3.4 2.6 2.0 Examples:
10 UC 1.00 128 37 30 25 18.6 14.9 12.4 9.9 7.4 3.4 2.3 1.7 1.4 TF-VS4 – Stainless Steel
TF-ɫ7.5 w/VisiFlo color-coding
20 UC 1.41 180 52 42 35 26 21 17.4 14.0 10.5 4.8 3.2 2.4 1.9
30 UC 1.73 221 64 51 43 32 26 21 17.1 12.8 5.9 3.9 2.9 2.4 TF-VP4 – Polymer w/VisiFlo
40 XC 2.00 256 74 59 50 37 30 25 19.8 14.9 6.8 4.5 3.4 2.7 color-coding
ɫ Specify material.
