Roller Pump Accessories

PART PTO (I.D.) PUMP END MATERIAL RPM FOR PUMP
NUMBER (I.D.) SERIES
ROLLER PUMP ADAPTERS FOR PTO AND GAS ENGINE ADAPTION
(FEMALE TO FEMALE)

1320-0015 3/4" 5/8" steel * 4000, 6500
1320-0016 5/8" 5/8" steel * 4000, 6500
1320-0076 1-3/8” (6 spline) 15/16" forged steel 540 1500, 1700, 7560, 7700 1320-0015
1320-0077 1-3/8” (6 spline) 5/8" forged steel 540 6500
1320-0078 1-3/8” (21 spline) 15/16" forged steel 1000 1500, 1700, 7560
1320-0079 1-3/8” (21 spline) 5/8" forged steel 1000 4000, 6500
1320-0080 1-3/4” (20 spline) 15/16" forged steel 1000 1500, 1700, 7560
1320-0081 1-3/8” (6 spline) 1" forged steel 540 5200
1320-0076
* Refer to the recommended pump rpm.

PART PTO (I.D.) PUMP END MATERIAL RPM FOR PUMP
NUMBER (I.D.) SERIES
ROLLER PUMP QUICK COUPLERS (FEMALE TO FEMALE) PUMPS
1323-0072 1-3/8” (6 spline) 15/16" forged steel 540 1500, 1700, 7560, 7700
1323-0073 1-3/8” (21 spline) 15/16" forged steel 1000 1500, 1700, 7560 1321-0006
1323-0074 1-3/8” (6 spline) 5/8" forged steel 540 6500
1323-0075 1-3/8” (21 spline) 5/8" forged steel 1000 4000, 6500
1323-0076 1-3/8” (muti-speed 15/16" forged steel 540/1000 1500, 1700, 7560, 7700
1323-0077 1-3/8” (muti-speed) 5/8" forged steel 540/1000 4000, 6500

1323-0073
Diaphragm Pumps

MODEL DESCRIPTION MAX MAX MAX
NUMBER GPM PSI RPM
LOW PRESSURE DIAPHRAGM PUMPS
9910-D70 2 - diaphragm pump - 1-1/4” HB inlet, 1” HB outlet. 19 290 550
Select shaft kit for desired drive
9910-D70GR 2 - diaphragm pump - 3/4" hollow shaft with gear 19 290 3600
reduction for 5 hp gasoline engine
9910-D115 3 - diaphragm pump - 1-1/2" HB inlet, 1” HB outlet. 30.1 290 550
Select shaft kit for desired drive. 9910-D70
9910-D115GR34 3 - diaphragm pump - 3/4" hollow shaft with gear 30.1 200 3600
reduction for 5 hp gasoline engine.
9910-D135 3 - diaphragm pump - 1-1/2" HB inlet, 1” HB outlet. 34.8 290 550
1-3/8"-6 splined male shaft.
9910-D160 4 - diaphragm pump - 2” HB inlet, 1-1/2" HB outlet. 42.5 290 550
1-3/8"-6 splined male shaft.
9910-D250 6 - diaphragm pump - 2” HB inlet, 1-1/2" HB outlet. 66 290 550
1-3/8"-6 splined male shaft.
9910-D250
