Quick TeeJet Single Nozzle Bodies

For Wet Booms

QJ22187-NYB
• Can be mounted to 1/2", 3/4", • Standard diaphragm of EPDM • Flow rate: 2.5 GPM (9.5 l/min)
1" pipe or equivalent size tubing. w/optional Viton available. at 5 PSI (0.34 bar) pressure
• 1/2" and 3/4" sizes include a • Mounts to a 3/8" (9.5 mm) hole drop, 3.54 GPM (13.4 l/min)
mounting hole in clamp drilled in pipe or tubing. at 10 PSI (0.69 bar) pressure
subassembly for mounting to • Maximum operating pressure drop.
flat surfaces. of 300 PSI (20 bar).
• Allows side mounting to flat
surface for protection of body. TO CLAMP DRILL HOLE UPPER CLAMP
• Features ChemSaver drip-free PART NUMBER ON SIZE BOLT SIZE
shutoff. Requires 10 PSI QJ22187-1/2-NYB 1/2" Pipe .375" (9.5 mm) 1/4"
QJ22187-NYB (0.7 bar) at the nozzle to open QJ22187-3/4-NYB 3/4" Pipe .375" (9.5 mm) 1/4"
check valve. QJ22187-1-NYB 1" Pipe .375" (9.5 mm) N/A

QJ17560A-NYB • All sizes include a mounting • Flow rate: 2.25 GPM
• Can be mounted to 20 mm, hole in upper clamp subassembly (8.5 l/min) at 5 PSI (0.34 bar)
25 mm, 1/2", 3/4" or 1" pipe for mounting to flat surfaces. pressure drop, 3.18 GPM
or equivalent size tubing. • Maximum operating pressure of (12.0 l/min) at 10 PSI
• Features ChemSaver drip- 300 PSI (20 bar). (0.69 bar) pressure drop.
free shutoff. Requires
10 PSI (0.7 bar) at the
nozzle to open check valve. TO CLAMP DRILL HOLE UPPER CLAMP BOOM COMPONENTS
• Standard diaphragm of PART NUMBER ON SIZE BOLT SIZE
EPDM with optional QJ17560A-1/2-NYB 1/2" Pipe .375" (9.5 mm) 5/16" or M8
Viton available. QJ17560A-3/4-NYB 3/4" Pipe .375" (9.5 mm) 5/16" or M8
• Mounts to a 3/8" (9.5 mm) QJ17560A-1-NYB 1" Pipe .375" (9.5 mm) 5/16" or M8
or 9/32" (7.0 mm) hole
QJ17560A-NYB drilled in pipe or tubing.

QJ7421-NYB
• Can be mounted to 1/2", 3/4" • Maximum operating pressure
or 1" pipe or equivalent size of 300 PSI (20 bar).
tubing.
• 1/2" and 3/4" sizes include a
mounting hole in upper clamp PART NUMBER TO CLAMP DRILL HOLE UPPER CLAMP
subassembly for mounting to ON SIZE BOLT SIZE
flat surfaces. QJ7421-1/2-NYB 1/2" Pipe .375" (9.5 mm) 1/4"
• Mounts to a 3/8" (9.5mm) QJ7421-3/4-NYB 3/4" Pipe .375" (9.5 mm) 1/4"
QJ7421-NYB hole drilled in pipe or tubing. QJ7421-1-NYB 1" Pipe .375" (9.5 mm) N/A
