Page 209 - 2022 Online Catalog

www.bigwsales.com

Diaphragm Pumps

PART DESCRIPTION MAX MAX PORT SIZE MAX
NUMBER GPM PSI DRAW
SLV SERIES AUTO DEMAND PUMPS 12 VDC
SLV10- Viton® valves, Santoprene® diaphragm, 1 30 2.5
40 PSI demand switch, Integral on/off
AA40 switch included
SLV10- Viton® valves, Santoprene® diaphragm, 1 30 3⁄8" Barb 2.5
AA41 40 PSI demand switch
SLV10- Viton® valves, Santoprene® diaphragm, 1 30 2.5
40 PSI demand switch, Manual switch
AA48 and 2 pin connector 12VDC SLV10-AA48

PART DESCRIPTION MAX MAX MAX
NUMBER GPM PSI DRAW
9300 SERIES SUBMERSIBLE PUMP 24 VDC
9325-043-101 EPDM valves, Santoprene® diaphragm 1.8 n/a 4.1

9325-043-101 PUMPS
Accessories

MODEL DESCRIPTION

ACCUMULATOR TANK, HEAT SINK

34-007 5" [12.7 cm] Heat Sink to assist cooling in Continuous-duty
applications
34-006 3" [7.6 cm] Heat Sink to assist cooling in Continuous-duty 34-007
applications

PART NUMBER DESCRIPTION

SWIVEL HEX WINGNUT STRAIGHT
234-2916 1⁄2" NPT-Female x 3⁄8" Barb - Polypro
234-2926 1⁄2" NPT-Female x 1⁄2" Barb - Polypro
234-2936 1⁄2" NPT-Female x 5⁄8" Barb - Polypro 234-2926
234-2946 1⁄2" NPT-Female x 3⁄4" Barb - Polypro
SWIVEL HEXNUT ELBOW
234-3926 1⁄2" NPT-Female x 1⁄2" Barb Swivel Hexnut Elbow - Polypro
234-3916 1⁄2" NPT-Female x 3⁄8" Barb Swivel Hexnut Elbow - Polypro
234-3946 1⁄2" NPT-Female x 3⁄8"" Barb Swivel - Polypro
234-3936 1⁄2" NPT-Female x 1⁄2" Barb Swivel - Polypro 234-3916
